4 MegaPixel Dual-Light Network Bullet Camera

Name: 4 MegaPixel Dual-Light Network Bullet Camera
Brand: Pollo

1/1.8'' Progressive Scan CMOS · 2560×1440 Pixels (2K) Resolution · 0.0001 Lux Min. Illumination for Day Time Color View

Buying for your business? Apply for a trade account

Product overview

• 1/1.8'' Progressive Scan CMOS
• 2560×1440 Pixels (2K) Resolution
• 0.0001 Lux Min. Illumination for Day Time Color View
• 30-meter Dual Night View Range
• Motion Detection Alarm Trigger
• Line Crossing Detection
• Region Intrusion Detection
• Highlight Compensation for Image Correction
• Backlight Compensation for Image Correction
• ONVIF Protocol Supported
• IP67 Water & Dust Proofing
• DC12V/ PoE (IEEE802.3af) Power Supply

Technical specifications

BLC	Yes
HLC	Yes
PoE	Yes, IEEE802.3af
ROI	Each ROI to be configured separately
Lens	2.8mm@F2.2, Horizontal FoV: 96°;Vertical FoV:53.7°;Diagonal FoV:112°
Audio	1CH built-in MIC
Focus	Fixed
Model	PLC-424P-AU-DL3/PM
Weight	( net ) Approx. 0.25KG
Network	RJ45
Storage	Environment - 20 °C ~ 60°C (-4°F~140°F), Humidity: less than 95 % (non-condensing)
Bit Rate	64 Kbps ~ 3 Mbps
Iris Type	Fixed Iris
Digital NR	Yes
Dimensions	( mm ) 162.1 × 74.8 × 73.8
Image Size	2560×1440
Lens Mount	M12
Resolution	4MP ( 2560 × 1440 ), 3MP ( 2304 × 1296 ), 1080P ( 1920 × 1080 ),720P ( 1280 ×
Sub Stream	D1/VGA/480× 240/CIF (60Hz: 1~30fps; 50Hz: 1~25fps)
Main Stream	4MP/ 3MP/1080P/720P (60Hz: 1~30fps; 50Hz: 1~25fps)
Image Sensor	1/1.8" Progressive Scan CMOS
Installation	Ceiling mounting; Wall mounting
Power Supply	DC12V/PoE
Video Output	No
Bit Rate Type	VBR / CBR
Image Settings	ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image
Angle Adjustment	Pan: 0°~360°; Tilt:0°~80°;Rotation: 0°~360°
General Function	Watermark, video mask, heartbeat
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, 802.1x, HTTP
Min. Illumination	0.0001 lux @F1.0, AGC ON; 0 lux (Illuminator on)
Online Connection	Support simultaneous monitoring for up to 3 users; Support multi-stream real
Power Consumption	< 5W
Remote Monitoring	Web browser /POLLO NVR/PVMS Plus/Pollo Live Plus Mobile App
Video Compression	Main stream: H.265+ / H.265 / H.264 + / H.264
Electronic Shutter	1 / 3s ~ 1 / 100000s
Ingress Protection	IP67
Interface Protocol	ONVIF
Wide Dynamic Range	120 dB
Operating Environment	- 20 °C ~ 55 °C (-4°F~131°F); Humidity: less than 95 % (non-condensing)
H.265 Compression Standard	Main Profile@Leve4.1 High Tier
