VisionBell - Outdoor Video Doorbell Terminal

Name: VisionBell - Outdoor Video Doorbell Terminal
Brand: Pollo

Full HD 1080P camera with 1/2.8” CMOS sensor · Ultra-wide 170° view with 2.3mm lens · 0 Lux Night Vision with white & IR light support

Buying for your business? Apply for a trade account

Product overview

• Full HD 1080P camera with 1/2.8” CMOS sensor
• Ultra-wide 170° view with 2.3mm lens
• 0 Lux Night Vision with white & IR light support
• H.265+ Compression for bandwidth & storage saving
• Face Detection & Face Capture supported
• IC Card Access Control (Mifare / Desfire – 13.56MHz)
• Built-in Mic & Speaker for two-way audio
• Door Control Ready – Lock, Exit Button & Door Contact
• PoE + DC12V Power options
• IP65 Weatherproof – suitable for outdoor use
• Mobile APP & CMS Remote Monitoring
• Micro-SD support up to 256GB

Technical specifications

BLC	Yes
HLC	Yes
PoE	Power Supply Yes
Lens	2.3mm @F2.2; Vertical FOV:74°，Horizontal FOV: 139°, Diagonal FOV:
Audio	Built-in MIC×1, built-in speaker×1
Model	PLC-VD1200/PM
Reset	Button 1
Network	100M RJ45
Storage	Network remote storage, micro SD card storage
Bit Rate	64Kbps ~ 4Mbps
Image Size	1920×1080
Lens Mount	M8
Resolution	1080P(1920×1080), 720P(1280×720), D1
Sub Stream	60Hz: 720P/D1/CIF(1~30fps); 50Hz: 720P/D1/CIF(1~25fps)
Main Stream	60Hz: 1920×1080/1280×720(1~30fps); 50Hz
Image Sensor	1/2.8" Progressive Scan CMOS
Installation	Wall mounting
Weight (net)	Approx.145g
General Function	Watermark, IP address filtering, video mask, heartbeat, illegal login,
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, UPnP,
Online Connection	Supports simultaneous monitoring for up to 3 users Supports multi-
Power Consumption	< 6W
Remote Monitoring	Web client/CMS remote control
Video Compression	H.265+/H.265/ H.264+/H.264/MJPEG
Electronic Shutter	1/2s ~ 1/100000s
Ingress Protection	IP65
Interface Protocol	ONVIF
Intelligent Analytics	Face detection, face capture, scene change detection, video blur
