SecurePad - Outdoor Video Access Control Terminal

Name: SecurePad - Outdoor Video Access Control Terminal
Brand: Pollo

Full HD 1080P face recognition terminal with dual wide-angle lens · 1/2.8” CMOS sensor with excellent low-light performance · 120dB WDR, 2D/3D DNR, BLC, HLC & Defog support

Buying for your business? Apply for a trade account

Product overview

• Full HD 1080P face recognition terminal with dual wide-angle lens
• 1/2.8” CMOS sensor with excellent low-light performance
• 120dB WDR, 2D/3D DNR, BLC, HLC & Defog support
• Ultra-wide field of view up to 170° diagonal
• Face detection, capture & comparison with high accuracy
• Supports face database up to 10,000 users
• Multiple access modes: Face / Card / Password / APP / Indoor station
• Supports IC & EM cards (13.56MHz & 125KHz)
• 3.5” built-in IPS screen for live preview and operation
• Mask detection & duress alarm supported
• Built-in microphone & speaker with noise cancellation
• Door access control integration (lock, exit button, door contact)
• Alarm I/O & anti-tamper protection
• Micro-SD storage up to 256GB
• PoE or DC12V power support
• Wi-Fi + Ethernet connectivity
• IP67 & IK04 protection for indoor/outdoor use
• Supports ONVIF, P2P & remote monitoring
• Multi-user online monitoring (up to 10 users)
• Compact wall-mount design

Technical specifications

BLC	Yes
HLC	Yes
PoE	Yes (802.3af)
Lens	M8 HD dual lens: 2.3mm@F2.2 Vertical FOV: approx. 74°，Horizontal
Audio	Built-in MIC×1, built-in speaker×1; support noise suppression and echo
Defog	Yes
Model	PLC-VD2200/PM
Reset	Yes
Network	Security Video encryption, firmware encryption, configuration encryption,
Storage	Network remote storage，SD card storage cloud storage
Bit Rate	64Kbps ~ 6Mbps
Image Size	1920×1080
Resolution	1080P (1920×1080), 720P (1280×720), D1, CIF, 480×240
Sub Stream	720P/D1/CIF (60Hz: 1~30fps; 50Hz: 1~25fps)
IR Distance	0.3-2m
Main Stream	1920×1080/1280×720(60Hz: 1~30fps; 50Hz: 1~25fps)
Image Sensor	1/2.8” Progressive Scan CMOS
Installation	Wall Mounting
Weight (net)	Approx. 0.6 kg
General Function	Watermark, IP address filtering, video mask, heartbeat, illegal login
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, UPnP,
Online Connection	Supports simultaneous monitoring for up to 10 users Supports multi-
Power Consumption	< 12W
Remote Monitoring	Web client/indoor station/CMS remote control
Video Compression	Main stream: H.265+/H.265/H.264+/H.264 Sub/third stream:
Electronic Shutter	Auto/Manual; Manual:1/2s ~ 1/100000s
Interface Protocol	ONVIF
Intelligent Analytics	Face detection, face capture, face comparison
